Prance, a leading provider of architecture facade systems, uses the 3D laser -Scan technology to change the design, manufacture and installation of complex curved aluminum curtain walls. In a number of top-class projects in China and Southeast Asia, Prance has set a new industry benchmark with this technology in order to carry out complex architectural designs with accuracy at millimeter level and at the same time revise, reduce material waste and building risks.
Precision -driven workflow: from the scan to installation
Central to this transformation is a seamless digital workflow that is integrated:
- Point cloud recording: high definitions 3D scanning of the building structure
- BIM/digital modeling: Accurate reverse engineering of location conditions
- Precision production: custom aluminum panel production based on digital data
- Leadership installation: Positioning on site using model derived coordinates and drawings
This end-to-end digital thread eliminates assumptions, ensures a perfect fit and enables the fast use even the most geometrically most complex curtain wall systems.
Important advantages of the 3D scan in external roofing projects
- Accuracy at the millimeter level: The traditional measurement often prevents aluminum panels from being installed and cutting and reworking on site. 3D laser scan with its accuracy at the millimeter level records the data on site and eliminates rework on site, cutting and adapting.
- Adaptability to complex shapes: The 3D scanning adapts exactly to complex structures such as stadium hyperboloids and specially shaped roofs, whereby the data is seamlessly transferred to the production to ensure a flawless design.
- Improved security and efficiency: This technology significantly reduces the work of the overhead costs and alleviate security risks. It also improves the installation efficiency through precise prefabrication and significantly shortens the design plans.
- Digital project archive: After completing the project, Point Clouds and BIM models form a permanent digital archive that provides precise component information for subsequent maintenance, repair and renovation, which enables the tracaability of the life cycle data for life cycle.
In addition, the use of high-performance aluminum panels ensures that the integrity of the design corresponds to the durability of the material durability. These panels offer excellent corrosion resistance, light weight and high strength and can be ended with fluorine fabric coatings, wooden grains or other user -defined surfaces in order to meet the aesthetic and performance requirements.
3D scan use projects according to Prance:
1. Xinjiang Circular Sports Center
This legendary circular stadium in Xinjiang needed a tailor -made aluminum panel -cladding system to meet the complex curvature. Conventional measurement methods proved to be inadequate, so
The procedure made it possible for each aluminum panel to be tailored to the facade in order to ensure a perfect fit and minimize material waste. The result was a long -lasting, visually striking exterior resistance to corrosion and extreme weather, whereby a digital recording was maintained for future maintenance.
2. Yibin Wuliangye Industrial Park
For this large commercial complex, prance 3D laser -Scan, digital modeling as well as custom panel and curtain wall production was used to ensure precise alignment and smooth integration. The use of scandates minimized errors improved the safety of workers by reducing manual measurements to a high level and enabled faster installation. The result was a modern facade with light, corrosion-resistant aluminum panels and high-performance glass curtain walls that improve natural light and energy efficiency.
3. Maoming Service Area petrol station Baldachin
The Maoming project included a curved leaf inspired by leaf. Its irregular geometry required accuracy that only 3D scanning could deliver.
The 3D scan used the prance project team to create a digital model of canopy and manufacture custom aluminum panels so that seamless installation is made possible with only minor adjustments. The solution improved the installation security, reduced rework and provided corrosion -resistant, light and visually modern canopy dessign.
4. Dongyang North Bahnhof Sonnenschild Baldachin
The Dongyang North Station in the province of Zhejiang needed a non-planar, curved sun protection roof that crossed the limits of the traditional panel design. Prance captured the complex geometry with accuracy at the millimeter level by 3D scan and enabled the production of custom panels, which perfectly matched the structure. These panels have a corrosion -resistant coating that ensures long -term shelf life outdoors and complements the architectural design of the station.
5. Thailand Phuket Chalong Bay Five Star Hotel
For this luxury resort, prance 3D laser scan, digital modeling, material selection, production and installation instructions. A comprehensive scan was completed in just three days, which provided precise data for BIM integration and efficient construction planning. Prance then provided custom-made exterior cladding systems and wooden grains aluminum ceilings, which provided fire safety, moisture resistance and aesthetic warmth in harmony with the design of the resort.
Driving accuracy, efficiency and sustainability
The consistent application of the 3D scan in the projects through prance shows measurable advantages:
- Accuracy: Panel at a millimeter level and costly rework.
- Efficiency: Shortened blueprints and reduced workers.
- Security: Less trust in dangerous manual measurements.
- Sustainability: Reduced material drop and completely recyclable aluminum panels.
By integrating progressive measurement and precision technology into its facade solutions, Prance sets a new industry benchmark for the provision of curved aluminum curtain walls, which are both visually breathtaking and technically flawless.
For each request, contact Prance at:
E -mail: info@prancebuilding.com,
Telephone AT +86-757-83138155,
Fax AT +86-757-83139722.
About the Prance building
Prance offers advanced aluminum panel and curtain wall solutions with specialist knowledge in 3D scanning, digital modeling and precision technology. Through innovative applications in various architecture projects in China and Southeast Asia, prance provides efficient, safe and sustainable building shell solutions. The company endeavors to deliver solutions for building envelope that combine accuracy, efficiency, security and sustainability.
